Electonic Enclosure
|
|
|
IP66 Protection Class Material
|
High Density P.U.Foam
|
|
|
Weight
|
< 1.5Kg
|
|
|
Dimensions
|
275 x 150 x 55mm
|
|
|
Connections
|
IP66 Lemp Connectors
|
|
|
Keypad
|
IP68 16Key tactile membrane
|
|
Supply Voltage
|
|
|
|
240Volts 50Hz
|
|
|
|
110Volts 60Hz
|
|
|
|
220Volts 50Hz
|
|
|
Mas. Power consumption
|
9 Watts
|
|
|
Output
|
9VDC Regulated
|
|
Battery Pack
|
|
|
4AA Nickel Metal Hydride
|
24hrs Operating Time
|
|
|
Recharge time
|
15hrs Charge Time
|
|
|
|
Low Battery Indication on Display
|
|
Display
|
|
|
240 64 Graphics LCD with backlight
|
|
Temperature
|
Operating
|
-20℃ to +70℃
|
|
|
Storage
|
-30℃ to +80℃
|
|
|
Max. Humidity at 40℃
|
|
|
Output
|
|
Display
|
Volumetric flow units
|
M3, gallons(Imperial and US), litres
|
|
|
Flow velocity
|
meters/sec, feet/sec
|
|
|
Flow Rate(4Singificant Figures)
|
|
|
Total Flow(12Digits)
|
Forward and Reverse
|
|
|
Continuous Battery Level Indication
|
|
|
Continuous Signal Level Indication
|
|
|
ERROR messages
|
|
Analogus
|
4-20mA into 750ℓ
|
User definable scaling
|
|
|
Resolution
|
0.1% of full scale
|
|
Printer/ terminal
|
Series RS232-C
|
Inc handshaking
|
|
|
|
User definable scaling
|
|
Data Logger
|
|
|
Memory capacity
|
100K (50,000 data points)
|
|
|
|
and 20 different site set-up's
|
|
|
Via RS232 or displayed graphically
|
|
|
Application Details
|
|
|
Flow Details
|
|
Transducer Sets
|
Frequency
|
Velocity Range Reflex(Diagonal Mode)
|
|
" B "
|
90mm ... 1000mm pipe
|
0.02 ... 6m/sec(16m/sec)
|
|
Standard
|
Temperature range
|
-20℃ to +150℃
|
|
Accuracy
|
|
|
1% of reading within velocity range or ±0.1m/sec
|
|
|
Specifition assumes turbulent flow profile with Reynod numbers above 4000
|
|
Pipe Materials
|
|
|
Any sonic conducting mediym such as Carbon Steel, Stainless Steel, Copper, UPVC,
|
|
|
PVDF, Concrete, Galvanised Steel, Mild Steel, Glass, Brass
|
|
|
Including Lined Pipes-Epoxy/ Rubber/ Steel/ Plastic
|
