세부사항
|
내 용
|
|
Operating principle (측정 원리)
|
Counts individual particles using scattered laser light
and calculates the equivalent mass concentration
using a proper algorithm.
|
|
Optical system (광학 시스템)
|
Sideway light-scattering method
|
|
Light source (광원)
|
Laser diode
|
|
Laser product class (레이저 관련 규격)
|
Class 1, IEC 60825-1 / EN 60825-1
|
|
Mass Mode (분진 측정 모드)
|
|
Mass concentration ranges (분진 범위)
|
PM1, PM2.5, PM4, PM7, PM10, TSP
|
|
Concentration range (농도 범위)
|
0~1000μg/m³
|
|
Sample time (샘플링 시간)
|
1 minute (2.83 L/min)
|
|
Count Mode (파티클 측정 모드)
|
|
Particle size (파티클 사이즈 – 8 채널)
|
0.5㎛, 0.7㎛,1.0㎛, 2.5㎛, 4.0㎛, 5.0㎛, 7.0㎛, 10.0㎛
|
|
Accuracy (정확도)
|
±10% to calibration aerosol
|
|
Sensitivity (감도)
|
0.5㎛
|
|
Sample flow rate (유량)
|
2.83 L/min
|
|
Maximum particle concentration
(최대 파티클 농도)
|
105,900 particles / L (coincidence loss max. 5%)
|
|
Sample time (샘플링 시간)
|
6 s. (0.01CF), 21 s.(1 L), 1 min.(0.1CF,2.83L),
3 min.53s(10L),10 min. (1 CF,28.3L),
any length (MANUAL), any length (1s. to 59min. 59s.)
|
|
Relative Humidity (상대 습도)
|
±7%, 20% to 90% RH non-condensing
|
|
Temperature (온도)
|
±3℃, 10℃ to 40℃ (50℉ to 104℉)
|
|
Data storage (데이터 저장)
|
500 sample records (rotating buffer) in Mass mode
500 sample records (rotating buffer) in Count mode
|
|
Data recorded (데이터 저장 항목)
|
Date, time, counts or mass, relative humidity,
temperature, sample volumes, alarms, label
|
|
Display (디스플레이)
|
TFT color display with backlightl
|
|
Interface (인터페이스)
|
USB
|
|
Dimension/Weight (크기/무게)
|
11.0 x 21.8 x 6.7 cm / 875g
|
|
Operating (작동 온도)
|
10 °C to 40 °C (50 °F to 104 °F), 20 % to 90 % RH,
non-condensing
|
|
Storage (보관 온도)
|
-10℃ to 50℃, 0% to 90%RH, non-condensing
|
|
AC adapter (어댑터)
|
12 VDC at 3A, 100 to 240V AC, 50/60 ㎐
|
|
Rechargeable Battery (충전 배터리)
|
Lithium ion, 8.4 V at 2.5 Ah; replaceable
|
|
Charge time (충전 시간)
|
2 hours (Fast Charge mode)
27 hours (Trickle Charge mode)
|
|
Continuous Operating Time
(작동 지속 시간)
|
4 hours
|
|
Standards (규격)
|
Complies with CE, JIS B9921: 1997, ISO 21501-04
|
|
Accessories (기본 악세사리)
|
Instruction manual, AC adapter, Power cord, USB Cable,
Zero count filter, Carrying case
|
