MODEL

DS-530SF

DS-530LF

Dimension (IN)

1000×600×1000(H)mm

1200×800×1200(H)mm

Dimension (OUT)

1180×810×1540(H)mm

1380×1010×1750(H)mm

Capacity

600 Liter

1152 Liter

Fan Motor

1/8HP×2EA

1/8HP×3EA

Type

Forced Convection

Temp.Controller

Digital P.I.D Controller

Temp.Range

40℃ to 250℃

Temp.Accuracy

1℃ at 100℃

Timer

Digital Timer 99hr 59min, or Infinity

Material (IN)

Stainless Steel (STS) Polishing Plate

Material (OUT)

SCP-1 With Powder Coating

Shelves

Stainless Steel-Punching Plate/wire 6EA

Door

Silicon Packing Door With Window

Safety Device

Hydraulic Temp Control, Auto Power Breaker

Power(AC 220V, 60Hz)

3KW

4.5KW

MODEL

DS-530SN

DS-530LN

Chamber

1000×600×1000(H)mm

1200×800×1200(H)mm

위 사양과 동일하며 자연 대류 방식 모델임.
